Nellcor OxiMax SRC-MAX User Manual

Specifications
38
Performance
Saturation (SpO2)
75% ±1 Sat Point
90% ±1 Sat Point
Pulse Rate
60 bpm ±1 bpm
200 bpm ±2 bpm
Light Levels
Low Level = 750 nAi ±10%
High Level = 3,000 nAi ±10%
(nAi = nano-Amperes photodetector current)
Modulation (%MOD)
Low Modulation = 0.4% to 0.6%
High Modulation = 4.5% to 5.5%
ECG
Analog Outputs (R-Wave)
Output 1: = RA (White)
Output 2: = LA (Black)
Output 3: = LL (Red)
This is a 3 lead ECG compatible output.
C-Lock
Output 1: SRC-MAX System Ground
