2 Pin Description and PCB Foot Print
2.1 Specifications and Pin Definition
Table 2-1 N10 specifications
Specifications
N10
Dimensions
(23.5±0.1) mm x (17±0.1) mm x (2.2±0.2) mm (H x W x D)
Weight
1.3 g
Package
64-pin LCC
Figure 2-1 Top view of N10 module
