Table 5-3 Transmitting power (DCS1800&PCS1900)
PCL
Transmitting Power
Threshold Range
0
30 dBm
±2 dBm
1
28 dBm
±3 dBm
2
26 dBm
±3 dBm
3
24 dBm
±3 dBm
4
22 dBm
±3 dBm
5
20 dBm
±3 dBm
6
18 dBm
±3 dBm
7
16 dBm
±3 dBm
8
14 dBm
±3 dBm
9
12 dBm
±3 dBm
10
10 dBm
±4 dBm
11
8 dBm
±4 dBm
12
6 dBm
±4 dBm
13
4 dBm
±4 dBm
14
2 dBm
±5 dBm
15
0 dBm
±5 dBm
5.2.2 Receiving Sensitivity
Band
Typical
GSM800&EGSM900
<-108 dBm
DCS1800&PCS1900
<-108 dBm
The data in the above tables is obtained by connecting the module to RF test instrument (e.g.
CMU200, CWM500, or Agilent8960) in lab tests. It is for reference only.
