NETGEAR D6300 User Manual

NETGEAR genie ADVANCED Home
45
D6300 WiFi DSL Modem Router
• Security. See Chapter 7, Security.
• Administration. See Chapte
r 8, Administration.
• Advanced Setup. See Chap
ter 9, Advanced Settings.
Setup Wizard
The NETGEAR genie installation process is launched the first time you set up the WiFi
modem router. After setting up the WiFi modem router the first time, if you want to perform
this task again, you can run Setup Wizard from the Advanced tab of the genie.
1. Select Setup W
izard to display the following screen:
2. Select either Yes or No, I want to configure the router myself. If you select No, you are
taken to the Internet Basic Settings screen (see Internet Basic Settings on page 30
).
3. If you selected Ye
s, click Next. A series of screens are displayed as the router discovers and
processes your Internet connection. Click Next when prompted to advance to the next
screen.

NETGEAR D6300 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Channels quantity	2 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Rack mounting	-
Frequency range	2.4 - 5 GHz
USB ports quantity	2
Minimum system requirements	Internet Explorer 5.0, Firefox 2.0, Safari 1.4, Google Chrome 11.0
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Product color	Black
Flash memory	128 MB
Certification	RoHS, CEC, WEEE, Wi-Fi
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	255 mm
Width	205 mm
Height	77 mm
Weight	654 g
