Hardware Setup
14
D6300 WiFi DSL Modem Router
6. Power On/Off button
7. AC power adapter input
Front Panel
The WiFi modem router front panel has the 5 status LEDs, icons, and ports shown in the
figure.
Power DSL Internet Wireless USB
Figure 4. Front panel LEDs
The following tables describe the LEDs and icons on the front panel from left to right.
