Page #62 background imageLoading...
Page #62 background image
USB Storage
62
D6300 WiFi DSL Modem Router
USB Drive Requirements
The WiFi modem router works with 1.0 and 1.1 (USB Full Speed) and 2.0 (USB High Speed)
standards. The approximate USB bus speeds are shown in the following table. Actual bus
speeds can vary, depending on the CPU speed, memory, speed of the network, and other
variables.
Table 10. USB drive speeds
Bus Speed/Sec
USB 1.1 12 Mbits
USB 2.0 480 Mbits
The WiFi modem router should work with most USB-compliant external flash and hard drives.
For the most up-to-date list of USB drives supported by the WiFi modem router, visit:
http://kbserver.netgear.com/readyshare
The WiFi modem router supports both read and write access for FAT16, FAT32, NTFS, and
Linu
x file systems (EXT2 and EXT3).
Note: Some USB external hard drives and flash drives require drivers to
be loaded into the computer before the computer can access the
USB device. Such USB devices do not work with the WiFi modem
router.
ReadySHARE Access
Once you have set up your WiFi modem router, you can connect any USB storage device
and share the contents with other users on your network.
You can access your USB device in any of the following ways:
On Windows 7, Windows XP, Windows Vista, and Windo
ws 2000 systems, select Start >
Run, and enter \\readyshare in the dialog box. Click OK.
On Windows 7, Windows XP, Windows Vista, and Windows 2000 systems, open Internet
Explorer or Sa
fari, and enter \\readyshare in the address bar.
On Mac OS X (version 10.2 or later), enter sm
b://readyshare in the address bar.
In My Network Places, en
ter \\readyshare in the address bar.
