Installation Guide for the Model FS562 and Model FS566 Fiber Switches
Cabling Guidelines C-5
Fiber Cable Specifications
Table C-2 lists the electrical requirements of fiber cable.
Table C-2. Electrical Requirements of Fiber Optic Cable
Specification Fiber Optic Cable
Number of strands Two
Cable type 62.5/125-
P
m
multimode fiber optic cable
Numerical aperture 0.275
Total link budget 11 db
Modal band 500 MHz-km
Zero dispersion wavelength 1295 to 1365 nm
Dispersion slope < 0.093 ps/nm
2
-km
