DescriptionNumber
Power 1, Power 2, and Fan LEDs1
Stack ID LED2
10GBASE-T ports, each with a port LED3
OOB port with port LEDs4
Stack Master LED5
Reset button6
Mini USB console port7
1000BASE-T PoE+ ports, each with two port LEDs8
10GBASE-X SFP+ ports, each with a port LED9
USB port10
Common components
From left to right, the front panel of the full 1G models with 10G uplinks provides the
following components:
Stack ID, Power 1, Power 2, Fan, Stack Master, and system LEDs (see LEDs, M4300
series 1G models with 10G uplinks on page 29).
Recessed Reset button.
One mini USB console port.
Depending on the model, twenty-four or forty-eight 10/100/1000 Mbps autosensing
1000BASE-T RJ-45 ports, each with a left LED and a right LED (see LEDs, M4300
series 1G models with 10G uplinks on page 29).
The LED functionality depends on the model:
- Non-PoE models. On model M4300-28G and model M4300-52G, the left LED
indicates the speed and the right LED indicates the activity.
- PoE models. On model M4300-28G-POE+ and model M4300-52G-POE+, the
left LED indicates the PoE status and the right LED functions as the combined
speed and activity LED.
Two dedicated 10GBASE-T autosensing ports, each with a combined speed and
activity LED (see LEDs, M4300 series 1G models with 10G uplinks on page 29):
- On model M4300-28 and model M4300-28G-POE+, these are port numbers 25
and 26.
- On model M4300-52G and model M4300-52G-POE+, these are port numbers
49 and 50.
Hardware Installation Guide26Hardware Overview
