DescriptionNumber
Power 1, Power 2, and Fan LEDs1
Stack ID LED2
USB port3
Stack Master LED4
Reset button5
Mini USB console port6
10GBASE-X SFP+ ports, each with a port LED7
Combo ports, each with a port LED:8
Ports 47F and 48F are 10GBASE-X SFP+ ports
Ports 47T and 48T are 10GBASE-T ports
Common components
From left to right, the front panel of the full 10G models provides the following
components:
•
Power, Fan, Stack Master, and Stack ID system LEDs (see LEDs, M4300X series full
10G models with RJ45/SFP+ combo ports on page 38).
Because models M4300-48X and M4300-48XF can support two PSUs, the front panel
provides both a Power 1 LED and Power 2 LED.
•
Recessed Reset button.
•
One mini USB console port.
•
One USB 2.0 port.
•
Depending on the model, twenty, twenty-two, forty-four, or forty-six ports, each with
a combined speed and activity LED (see LEDs, M4300X series full 10G models with
RJ45/SFP+ combo ports on page 38).
•
Depending on the model, either two 10GBASE-X/10GBASE-T combo ports or four
10GBASE-T/10GBASE-X combo. ports, each with a combined speed and activity
LED (see LEDs, M4300X series full 10G models with RJ45/SFP+ combo ports on
page 38).
