Reference Manual for the ProSafe VPN Firewall FVS114
Maintenance 7-3
202-10098-01, April 2005
Click Show WAN Status to display the WAN connection status.
Figure 7-2: WAN Connection Status screen
This screen shows the following statistics:.
Log action buttons are described in Table 7-2
Table 7-1. Connection Status fields
Field Description
Connection Time The length of time the firewall has been connected to your Internet service provider’s
network.
Connection Method The method used to obtain an IP address from your Internet service provider.
IP Address The WAN (Internet) IP address assigned to the firewall.
Network Mask The WAN (Internet) subnet mask assigned to the firewall.
Default Gateway The WAN (Internet) default gateway the firewall communicates with.
Table 7-2. Connection Status action buttons
Button Description
Renew Click the Renew button to renew the DHCP lease.
