NETGEAR ProSafe FVS114 User Manual

Reference Manual for the ProSafe VPN Firewall FVS114
Basic Virtual Private Networking 5-5
202-10098-01, April 2005
VPN Tunnel Configuration
There are two tunnel configurations and three ways to configure them:
• Use the VPN Wizard to configure a VPN tunnel (recommended for most situations):
— See “How to Set Up a Client-to-Gateway VPN Configuration” on page 5-5.
— See “How to Set Up a Gateway-to-Gateway VPN Configuration” on page 5-20.
• See Chapter 6, “Advanced Virtual Private Networking” when the VPN Wizard and its VPNC
defaults (see Table 5-1 on page 5-4) are not appropriate for your special circumstances.
How to Set Up a Client-to-Gateway VPN Configuration
Setting up a VPN between a remote PC running the NETGEAR ProSafe VPN Client and a
network gateway (see Figure 5-3) involves the following two steps:
• “Step 1: Configuring the Client-to-Gateway VPN Tunnel on the FVS114” on page 5-6 uses the
VPN Wizard to configure the VPN tunnel between the remote PC and network gateway.
• “Step 2: Configuring the NETGEAR ProSafe VPN Client on the Remote PC” on page 5-9
configures the NETGEAR ProSafe VPN Client endpoint.
Figure 5-3: Client-to-gateway VPN tunnel
192.168.3.1
VPN Tunnel
FVS114
24.0.0.1
PC
(Running NETGEAR
ProSafe VPN Client)
PCs
