Reference Manual for the ProSafe VPN Firewall FVS114
3-4 Connecting the Firewall to the Internet
202-10098-01, April 2005
Figure 3-4: Status lights
d.
Check the VPN firewall router status lights to verify the following:
PWR: The power light should turn solid green. If it does not, see “Troubleshooting
Tips” on page 3-6.
TEST: The test light blinks when the firewall is first turned on then goes off. If after
two minutes it is still on, see “Troubleshooting Tips” on page 3-6.
INTERNET: The Internet LINK/ACT light should be lit. If not, make sure the Ethernet
cable is securely attached to the VPN firewall router Internet port and the modem, and
the modem is powered on.
LOCAL: A LOCAL light should be lit. Green on the 100 line indicates your computer
is communicating at 100 Mbps; off on the 100 line indicates 10 Mbps. If a LOCAL
light is not lit, check that the Ethernet cable from the computer to the firewall is
securely attached at both ends, and that the computer is turned on.
Now, Configure the FVS114 for Internet Access
1. From the Ethernet connected PC you just set up, open a browser such as Internet Explorer or
Netscape® Navigator.
Power Internet Local Port 4Test
