Reference Manual for the ProSafe VPN Firewall FVS114
Advanced Configuration 8-5
202-10098-01, April 2005
Using the LAN IP Setup Options
The LAN IP Setup menu allows configuration of LAN IP services such as DHCP and RIP. From
the main menu of the browser interface, under Advanced, click on LAN IP Setup to view the
menu shown below.
Figure 8-3: LAN IP Setup Menu
Configuring LAN TCP/IP Setup Parameters
The firewall is shipped preconfigured to use private IP addresses on the LAN side, and to act as a
DHCP server. The firewall’s default LAN IP configuration is:
• LAN IP addresses—192.168.0.1
• Subnet mask—255.255.255.0
Note: If your ISP assigns a private WAN IP address such as 192.168.x.x or 10.x.x.x, the
dynamic DNS service will not work because private addresses will not be routed on the
Internet.
