NETGEAR Stora User Manual

Stora Hardware
18
NETGEAR Stora
 To eject a disk:
1. Open the Stora Application user interface.
2. Select Preferences > Administration > Disk Management.
3. Click the Eject button for the disk you want to eject.
See Disk Management on page 107 for more information about ejecting disks
 To replace a disk:
1. View the disk status LEDs to identify which disk has failed.
If necessary, unlock the tray lock by moving it to the right and press the release of the
failed disk. The latch pops out.
2. Pull out the disk and replace it with a new disk.
3. Slide the disk tray back into the unit and secure the latch.
Note: To protect against data loss, add a second disk to your Stora to be
used as a mirrored backup of the data on the first disk.

NETGEAR Stora Specifications

General

Storage drive size	3.5 \
Hot-swap drive bays	-
Storage drive capacity	1000 GB
Storage drive interface	Serial ATA II
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	1 TB
Maximum supported storage capacity	2 TB
Number of storage drives installed	1
Number of storage drives supported	2
Flash memory	256 MB
Internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Minimum system requirements	Microsoft Internet Explorer 6.0+, \\r Netscape Navigator 7.0, \\r Safari 1.22+, \\r Mozilla Firefox 1.03+
Compatible operating systems	Microsoft Windows Vista, XP Home / Pro (SP1 / SP2), Macintosh OS X, Linux
Wi-Fi	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Type	Storage server
Device class	Home & Home Office
Power supply location	External
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	146 mm
Width	150 mm
Height	175.25 mm
Weight	1360 g
