Wireless-N 150 ADSL2+ Modem Router DGN1000 User Manual
Advanced Configuration 5-7
v1.1, January 2010
2. Enter the LAN Setup configuration. The fields in this screen are explained in Table 5-2 on
page 5-7
3. Click Apply so that your changes take effect.
Table 5-2. LAN Setup Fields
Field Description
IP Address The LAN IP address of the wireless modem router.
IP Subnet Mask The LAN subnet mask of the wireless modem router. Combined with
the IP address, the IP subnet mask allows a device to know which other
addresses are local to it, and which must be reached through a
gateway or wireless modem router.
RIP Direction Router Information Protocol (RIP) allows a wireless modem router to
exchange routing information with other routers. The RIP Direction
selection controls how the wireless modem router sends and receives
RIP packets. Both is the default setting.
• When set to Both or Out Only, the wireless modem router
broadcasts its routing table periodically.
• When set to Both or In Only, the wireless modem router incorporates
the RIP information that it receives.
• When set to None, the wireless modem router does not send any RIP
packets and ignores any RIP packets received.
RIP Version This controls the format and the broadcasting method of the RIP
packets that the wireless modem router sends. It recognizes both
formats when receiving. By default, this is set for RIP-1.
• RIP-1. This version is universally supported. RIP-1 is probably
adequate for most networks, unless you have an unusual network
setup.
• RIP-2. This version carries more information. Both RIP-2B and RIP-
2M send the routing data in RIP-2 format.
• RIP-2B. This version uses subnet broadcasting.
• RIP-2M. This version uses multicasting.
Access Router Management
Interface on additional port
When NAT is disabled, the wireless modem router’s management
interface may be accessed at the wireless modem router’s LAN
address using the port number you enter. This feature is not available
when NAT is enabled.
Use Router as DHCP Server See “Configuring DHCP” on page 5-8.
Address Reservation See “Configuring Reserved IP Addresses” on page 5-9.
