11 DISMANTLING AND ASSEMBLY
OF THE CONNECTING SHAFT
PAGE
11.0
date name signed revision:
issued 24.06.03 Mangel substitute for the issue
approved 25.06.03 Denk dated
released 25.06.03 Denk
text no. 30100
copy to:
11 Removal and Fitting of the Connecting Shaft
with Shaft Seal
Removal:
■ Push the circlip (1035) in the direction to the mechanical seal.
■ Remove pin (1030).
■ Remove the shaft seal housing (7005) and mechanical seal (7010)
together with connecting shaft (1050) and set ring (1035) from
drive stool (0085) and the drive shaft.
The thread of cylindrical head screw (1040) can be used as
forcing screw.
■ If a mechanical seal is installed, see description
"Removal and Fitting of Mechanical Seal" after Page 12.0.
Fitting:
■ Apply grease into the bore of the connecting shaft (1050) to avoid
rust (e.g. TCE-Metallic 600).
■ Assemble the shaft seal housing (7005) and mechanical seal (7010)
together with connecting shaft (1050) and set ring (1035) with
drive stool (0085) and push connecting shaft (1050) on to the
drive shaft.
At this please observe the installation direction of set ring (1035)
(please see mark).
■ If a mechanical seal is installed, see description
"Removal and Fitting of Mechanical Seal" after Page 12.0.
■ Connect the connecting shaft (1050) and the drive shaft by
pin (1030).
Push set ring (1035) on pin (1030).
