Connections
2-2
N
You can only use the C80 with Newall Spherosyn and Microsyn
analogue encoders.
You need to ensure that:
• You secure all the cables to prevent the connectors from
dropping into hazardous positions (for example the floor or
coolant tray) when you unplug them.
• You route all the cables to prevent them from being caught
on moving parts.
• The C80 is grounded to the machine, using the braided
grounding lead provided, before you turn on the machine
supply.
• You turn off the power by disconnecting the power supply
connector, before you connect the encoder.
Do not connect this unit directly to the mains supply.
If your Newall encoder is not fitted with a D-type connector, then
you can buy an adaptor cable (part no. 307-80980). Contact
your supplier for details.
