Set up
5-2
N
The following instructions are important and should be
followed carefully.
When you have finished setting all the options:
1. Press the down navigation key until ‘StorE’ appears in
the middle display.
2. Press [ent] to store any changes that you have made.
The middle display shows ‘StorEd’ for a few seconds as
your settings are stored.
The C80 leaves Setup Mode.
Alternatively, you can press [set up] at any time to leave the
Setup Mode and abandon any changes.
Machine type
You use this option to choose whether the special functions for
Mill or Lathe are available.
There are three possible settings:
Press the Select Key next to the ‘t’ to cycle through these
settings.
Encoder
The Encoder settings must match the actual encoder in use,
or the C80 will not display correctly.
Encoder type
There are three possible settings for each axis:
Press the Select Key next to the ‘X’, ‘Y’ or ‘z’ to cycle through
these settings.
Encoder resolution
The Resolution settings available for each axis depend on the
encoder type and the [in/mm] setting.
Generic gEnEric all functions available
Mill miLL mill functions only
Lathe LAtHE lathe functions only
Spherosyn SPHEroSn
Microsyn 10 uSn 10
Microsyn 5 uSn 5
Display Spherosyn
Microsyn
10
Microsyn
5
µm mm in
1 0.001 0.00005 X
2 0.002 0.0001 X
