Axis summing
5-11
N
All other connections are reserved and should be left
unconnected or the unit may be damaged.
Operation
You configure the RS232 output from the setup menu, using the
following settings:
• ‘SEriAL’ refers to the mode of operation. This can be
‘ConStAnt’, ‘SingLE’ or ‘nOnE’. You press the left
or right navigation key to cycle through the options.
• ‘SEr rAtE’ refers to the rate at which RS232 data is
generated when in constant mode. It shows a value (in
seconds) in the second axis window. You press the arrow
button next to the value to change the serial rate. You can
select values in the range 0.1 – 60.0 in 0.1s increments.
The maximum serial rate is limited by the baud rate, as
shown in the following table.
• ‘bd rAtE’ relates to the baud rate of the RS232
communications. The second axis window shows the
current value. You press the left or right navigation key to
select a value.
• ‘PAritY’ refers to the parity mode of the RS232
communications. The second axis window shows the
current setting. This can be ‘EUEn’. ‘Odd’ or ‘nOnE’. You
press the left or right navigation key to scroll through the
options.
Axis summing
This setting works in conjunction with the Summing function.
Two of the axis displays show ‘Addition’.
Press the Select Keys to switch between the two settings, X,Z
and Z,Z’.
Baud Rate Maximum Serial Rate (s)
300 2.0
1200 1.0
2400 1.0
4800 1.0
9600 0.5
14400 0.5
19200 0.5
38400 0.5
Baud Rate Maximum Serial Rate (s)
