Set up
5-1
N
Set up
This chapter describes how to set up the C80.
Setup mode
Normally, you only need to set up the C80 once. You may find
that the factory default settings are suitable so you do not need
to change them.
To enter Setup Mode:
1. Leave any Special Function that is running.
2. Press [set up].
The centre display shows ‘SEt Up’.
3. Press the up or down navigation key to cycle through the
list of options.
The following table lists the options. The following sections
describe each of the options in detail.
The options available depend on the setting of other options. For
example, the Zero Approach Limit option is not present if Zero
Approach is off.
Option Default Display
Machine Type Generic gEnEric
Encoder Type all axes: Spherosyn SPHEroSn
Encoder Resolution all axes: 0.005mm 0.005
Radius / Diameter all axes: Radius rAD
Direction all axes: 1 dir. 1
Error Compensation all axes: Off Err OFF
Linear Compensation see note below
Segmented
Compensation
see note below
Axis Summing X and Z’ axes Addition
RS232 Options None nOnE
Serial Rate 1.0 1.0
Baud Rate 9600 9600
Parity None nOnE
Zero Approach On / Off all axes: Off ZErO OFF
Zero Approach Limit see note below
Taper Display Axis X axis tAPEr On
Reset rESEt
Store StorE
Option Default Display
