Mountings
3-1
N
Mountings
This chapter shows the various options for mounting the C80.
You can mount the C80 in a variety of ways. The one that you
use depends on the mounting assemblies that you purchased
with the unit:
Arm mounting (non-adjustable)
Arm mounting (adjustable)
Face mounting (adjustable)
Mounting Arm Assembly
UK part no. 294-35675
US part no. FX0000SS-N
M10 stud & fixings,
supplied as standard
Arm Mount Adjustable Pivot
Assembly
Part no. 600-80290
Mounting Arm Assembly
UK part no. 294-35675
US part no. FX0000SS-N
Face Mount Adjustable
Pivot Assembly
Part no. 600-80270
