Newmac LFR-75 - Nh3 Parts List

24
TABLE 8, NH3 PARTS LIST
ITEM PART NO.
DESCRIPTION ITEM PART NO. DESCRIPTION
1 4110400
BASE PANEL
25 A
TWO SPEED FAN & LIMIT
2 4110401
SIDE PANEL R.H.
2010024
HONEYWELL L6064A 1086B (8")
3 4110402
SIDE PANEL L.H.
25 B
SINGLE SPEED FAN & LIMIT
4 4110403
REAR PANEL
2010025
HONEYWELL L4064B 2608 (8")
5 4110404
FAN PARTITION WHITE ROGERS E12(t)5D51-90 (8")
6 4110407
BURNER ACCESS PANEL
26 4110409
TOP PANEL
7 4110406
BLOWER ACCESS PANEL
27 4110180
TOP RAIL
8 4110405
FRONT PANEL
28 4120477
INSPECTION DOOR ASSEMBLY
9 2080054
FRONT PANEL GASKET
29 A 2110040
OIL BURNER - AERO HF-US-2X
10 4110408
CLEAN OUT PANEL
29 B 2110129
OIL BURNER - BECKETT AFG-AF60YHHS
11 4160201
HEAT EXCHANGER ASSEMBLY
29 C 2110033
OIL BURNER- CARLIN EZ-PRO
12 2080055
CLEANOUT COVER GASKET
29 D 2110031
OIL BURNER - RIELLO 40 F3
13 4060401
CLEANOUT COVER
29 E 2110032
OIL BURNER - RIELLO R35.3.05
14 4050115
BLOWER ELECTRICAL BOX ASSEMBLY
30 4110410
WIRE PANEL
15 4060402
COMBUSTION CHAMBER PLATE
31 4110412
FILTER RACK ASSEMBLY
16 2030008
COMBUSTION CHAMBER
32 2200010-2
48" BLOWER WIRE HARNESS (4 Wire)
17 4060403
COMBUSTION CHAMBER SUPPORT
2240034
FAN BELT - 1/2" X 34"
18 2080056
CHAMBER PLATE GASKET
2240035
FAN BELT - 1/2" X 35"
19 4110413
INSPECTION DOOR HOUSING
2240006
BLOWER PULLEY - 6" X 3/4"
20 2080007
INSPECTION DOOR GASKET
2240005
BLOWER PULLEY - 5" X 3/4"
21 A 2040114
DIRECT DRIVE BLOWER - DELHI G9-DD
33 41100140
BURNER CABLE (30" wire/18" conduit)
21 B
DIRECT DRIVE BLOWER - TORIN - DC 916 916 5
34 2200101
4" X 4" JUNCTION BOX
21 C 2040115
DIRECT DRIVE BLOWER - DELHI - G10-8 DD
35 2200103
4" X 4" JUNCTION BOX COVER
21 D 2040145
DIRECT DRIVE BLOWER - DELHI - GT12-7 DD
36 3100341
SMOKE BAFFLE
21 E
DIRECT DRIVE BLOWER - LAU - DD12-8AT
37 2180004
16" X 24" FILTER
4050117
1/2 hp, G9 DIRECT DRIVE BLOWER ASSEMBLY
2040019
5" DRAFT REGULATOR
2040113
BELT DRIVE BLOWER - DELHI G9 CLEAN OUT BRUSH
BELT DRIVE BLOWER - TORIN - BC 916 916 THERMOSTAT
4050105
1/2 hp, G9 BELT DRIVE BLOWER ASSEMBLY
2010001
HONEYWELL - T822D
22 A 2010040
5 uF 370 V CAPACITOR (used with 23 A & 23 B)
2010057
WHITE ROGERS - 1F30
22 B
10 uF 370 V CAPACITOR (used with 23 C) THERMOSTAT - HEATING/COOLING (optional)
22 C 2010052
20 uF 370 V CAPACITOR (used with 23 D)
2010027
HONEYWELL - T87F
23 A 2020007
1/3 hp DIRECT DRIVE BLOWER MOTOR (Emerson)
2010042
HONEYWELL SUBBASE - Q539A
23 B 2020008
1/2 hp DIRECT DRIVE BLOWER MOTOR
(Emerson)
HONEYWELL T8034 C
23 C
1/2 hp DIRECT DRIVE BLOWER MOTOR (A.O. Smith)
2200258
LOW SPEED ROCKER SWITCH (SPST, 15 AMP)
23 D 2020022
3/4 hp DIRECT DRIVE BLOWER MOTOR (A.O. Smith) FAN CENTER (optional)
BELLY BAND ASSEMBLY (includes band & arms)
2010059
WHITE RODGERS - 8A94-51 (DPDT for up to 3/4 hp)
2020003
1/2 hp BELT DRIVE BLOWER MOTOR
2010041
HONEYWELL - R8285A (SPDT for up to 1/2 hp)
2240001
3-1/4" X 1/2" VARIABLE SPEED PULLEY
2010015
HONEYWELL - R8405A (SPST for up to 1/2 hp)
24 4110414
FAN SLIDE HONEYWELL - R8405B (SPDT for up to 1/2 hp)
