TABLE 10 RIELLO BURNER PARTS LIST
ITEM PART NUMBER BURNER MODEL DESCRIPTION
F3 & F5 BF3 & BF5 RIELLO NEWMAC F3 F5 BF3 BF5
1 3006911 2090055
X X
Hydraulic jack
2 3006912
X X
Capillary tube
3 3000878
X X
Hydraulic air shutter
4 34 3005708
X X X X
Fan
5 33 3005844 2090041
X X X X
Capacitor 12.5 uF
6 3006993
X X
Pipe connector-return
7 3005847
X X
1/4" NPT/metric adapter-female
8 3006992
X X
Pipe connector-supply
9 3006571
X X
3/8" NPT/metric adapter-male
10 2 3007077
X X X X
Crushable metal washer 3/8" ID
11 4 3007028
X X X X
O-ring - pump pressure regulator
12 6 C7010002 2090043
X X X X
O-ring - pump cover
13 7 3005719
X X X X
Pump screen
14 8 3006036
X X X X
Valve stem
15 10 3007029
X X X X
O-ring valve stem,upper
16 11 3007156
X X X X
O-ring valve stem,lower
17 12 3007268
X X X X
Nozzle outlet fitting
18 14 3006553
X X X X
Coil U-bracket retainer nut
19 15 3002279
X X X X
Coil
20 16 3007802 2060007
X X X X
Pump
21 17 3000443
X X X X
Pump drive key
22 18 3005843
X X X X
Motor
23 9 3007203
X X X X
Plate - valve stem retainer
24 20 3002278
X X X X
Primary control sub-base
25 21 3001157 2010048
X X X X
Primary control 530 SE/C
26 22 3002280 2010045
X X X X
Photo cell
27 3005854
X X
Semiflange (2 Req'd)
28 24 3005855
X X X X
Universal mounting flange
29 25 3005856 2080058
X X X X
Mounting gasket
30 5 N/A
X X
Regulator
31 19 3007315
X
Air tube cover plate
3007316
X
Air tube cover plate
32 3007221
X
Chassis front plate
3007222
X
Air intake housing
33 3007204
X X
Manual Air Shutter
34 32 3007207
X X
Air intake housing
3007208
X
Air intake housing
32 3007824
X
Air intake housing
35 3007232
X
Burner back cover
3007233
X
Burner back cover
1 3008019
X
Burner cover
