4.7.1.2 The Parameters of the Ethernet Interface
The displayed parameters and their description:
Parameter Description
Ethernet
Eth MAC address MAC address of the Ethernet interface
Management IP address Management IP address of the Ethernet interface
Netmask
Network range for the user's LAN
VLAN Overview
Logical Interface Logical interface used on the modem within the network
Virtual Network Name of the virtual network the modem belongs to.
An MDM3x00 can belong to 8 different networks.
Gateway Address (IPv4) IPv4 address used as gateway address for the connected CPEs
within that network
Gateway Netmask
(IPv4)
Network range for the user's LAN within that network
Gateway Address (IPv6) IPv6 address used as gateway address for the connected CPEs
within that network
Gateway Netmask
(IPv6)
Network range for the user's LAN within that network
DHCPv4 enabled Indicates whether the DHCP server on the terminal is enabled or
not.
• The VLAN Overview parameters are signaled from the hub towards the modem.
These parameters are set by the Service Provider and cannot be edited by the end
user.
• In ExpertModeonpage62, two additional parameters are displayed: DHCP TFTP
server & DHCP TFTP file.
These two parameters are legacy and can be ignored.
