Modem Web Interface
User Manual MDM3X00
4.7.2.1 Viewing the Satellite Interface Configuration
Maximum two initial receive carrier settings and pointing carrier settings can be assigned and
displayed. Only the settings that are enabled are displayed. How to change the satellite interface
configuration is described in section EdittheSatelliteInterfaceConfigurationonpage35.
If two initial receive carriers are enabled and displayed, the preferred initial receive carrier is
marked green. If two pointing carriers are enabled and displayed, the default pointing carrier is
marked green.
The pointing carrier that is used for pointing is selected through the Terminal Installation
menu. Refer to TerminalInstallationonpage15 for more details.
The parameter values in the figure below are just an example. They are randomly
chosen and may therefore differ from the predefined settings on your modem.
If multiple beams are configured, you can select another beam from the dropdown list in the General
section to view its satellite settings. Changing the active beam is done via the Terminal Installation
menu.
