Newtec MDM3300 - Modifying the Ethernet Interface Configuration; Satellite Interface

R3.1_v1.2
32/76
Modem Web Interface
User Manual MDM3X00
4.7.1.3 Modifying the Ethernet Interface Configuration
• Click Edit in the Web Interface > View Configuration Ethernet interface to change the Ethernet
Settings.
• Edit the parameters to be changed.
• Click Save in the Web Interface > Edit Configuration Ethernet interface to save the new
settings.
The Ethernet interface configuration is now saved.
4.7.2 Satellite Interface
This section describes the interface settings between the terminal and the satellite.
The satellite interface settings are predefined in factory. These settings may only be
changed upon advice of your Service Provider!
A satellite beam covers a limited geographical area in which terminals are serviced by
the satellite.
The displayed satellite interface settings depend on the beam that was selected during
the terminal installation.
Refer to TerminalInstallationonpage15 for more information.
Every satellite interface setting consists of:
Initial Receive Carrier
This is the initial receive carrier through which the modem will try to gain access to the network.
Pointing Carrier
This carrier is needed to enable antenna pointing via the Point&Play mechanism or the automatic
pointing method. When two different pointing carriers are assigned to the terminal, the installer can
perform his pointing on two different pointing carriers. At least one pointing carrier must be enabled.
Maximum two satellite interface settings per beam can be assigned to the terminal. This is for
redundancy or migration reasons. In case two initial receive and/or pointing carriers are assigned to
the terminal, one preferred carrier is marked.
In case no carrier setting is configured, no carrier setting is shown in the GUI.
