R3.1_v1.2
38/76
Modem Web Interface
User Manual MDM3X00
Parameter Description
ACU IPv4 Address IPv4 address of the ACU.
Modem uses the entered IP address to reach the ACU. Make sure
the management IP address of the modem and the ACU are in the
same IP subnet.
ACU TCP Port TCP port of the ACU.
Modem uses the entered TCP port to reach the ACU.
Timeout Requested Keep alive time in which the modem asks the ACU to send its GPS
coordinates and the antenna status.
Timeout Tolerance If the modem does not receive the status within this time interval, the
modem switches back to pointing mode.
Use L-Band Frequency Check box to indicate if modem sends L-band frequency or RF
frequency to the ACU.
TX Polarization Indicates the polarization of the signal transmitted by the modem, as
the ACU can support both co- and cross polarization and might
expect this value from the modem.
