c. Installing CUs
CU Wall Bracket Mounting
The CU comes with a wall mounting bracket in the box. To mount the QUATRA EVO CU,
follow these steps:
1. Determine the mounting location. Note: Whenever mounting any CEL-FI gear on a wall or
ceiling, make sure the area is free of any electrical wires, other safety hazards, or any other
objects that could be damaged or affect the quality or stability of the mounted unit.
2. Position the QUATRA EVO CU wall mount on the wall in the desired mounting location.
3. Holding the mounting bracket in place, mark hole locations with a pencil.
4. Drill the holes.
5. Hammer in the anchors.
