May 2023 6
II. CEL-FI QUATRA EVO Key Features
• Carrier Grade, FCC-certified Part 20 Smart Signal Booster (operator Retransmission
Agreements are not required)
• Support for AT&T, Verizon, and T-Mobile (other operators may be requested)
• Relays four bands for one (1) operator, or two bands for each of two operators
• Independent operator donor ports allow for independent operator optimization
• Single combined (CU) server port enables driving either a serving antenna or passive DAS
field
• 100 dB max system gain per channel
• Support for up to six (6) CUs (twelve with a HUB)
• N-type(f) RF connectors (donor and server)
• Internal modem for remote management (SIM slot access)
• Industrial aluminum powder-coated housing
• Up to 100m cable distance between NU and CU (using Category cable)
• QUATRA Range Extender (QRE) doubles CU cable length (up to 200m)
• The Fiber QRE can further extend CU cable length an additional 2km
• 20-22 dBm uplink power per operator per band
• up to 16 dBm downlink power per cellular channel
Deploy With Confidence
CEL-FI QUATRA EVO is designed to improve indoor signal coverage without any risk of
interference to the mobile network. CEL-FI QUATRA EVO provides a sophisticated network-
safe solution that has been rigorously tested globally, through multiple generations, and
engineered to deliver multiple levels of network protection:
• Uplink gain and power control to prevent desensitizing the network
• Echo-cancellation and feedback control to prevent oscillation of the system
• Uplink muting, when handset (UE) use is not detected
• Signal qualification (channels are individually qualified, so noise or very poor signals won’t
be amplified and degrade the network)
• The CEL-FI WAVE Platform cloud-based portal enables remote monitoring of the
equipment and network KPI’s, such as channel configurations, RSRP, RSRQ, SINR, and
system gains, providing control and optimization insight.
Single Operator Mode:
Other operator configurations
Band options as indicated in Settings
