Nexus NX2 - 3.3 Cable Connections; Initial Setup and Operation

GPS NAVIGATOR
3.3 CABLE CONNECTIONS
The 3 m red and black power cables connect 12 V supply, ALWAYS USE WITH 3A
FUSE.
Cable wiring on the instruments backside.
NEXUS databus and power. +12V GREEN
DATA YELLOW
DATA WHITE
GROUND SCREEN
NMEA 0183 output A. TERMINAL 1
(RS 422) output B. TERMINAL 2
NMEA 0183 input. TERMINAL 3
(Opto)return TERMINAL 4
16
