Circuit board and electronics
Communication board (AA23)
1 Remove the top cover.
2 Remove the front panel.
3. Disconnect the cables.
4. Remove the six pins and
remove the circuit board.
5. Assembly takes place in
the reverse order.
NIBE™ F2040Chapter 7 | Component replacement86
