Nibe F2040 Technical Manual

Control board (PWB1) 8 kW
1 Remove the top cover.
2 Remove the front panel.
F2040 8 kW (upper side)
Screw
Screw
3. Remove the screws in the
corners of the board.
F2040 8 kW (underside)
87Chapter 7 | Component replacementNIBE™ F2040

Nibe F2040 Specifications

General

Type	Air/water heat pump
Refrigerant	R410A
Operating Temperature Range Heating	-20°C to 35°C
Operating Temperature Range Cooling	10°C to 46°C
Sound Power Level	56-62 dB(A) (depending on model)
