Nibe F2040 Technical Manual

4. Disconnect the cables
from their mountings so that
the card can lifted slightly.
5. Count and note the num-
ber of disconnected cables.
6. Carefully lift the side cir-
cuit board nearest you and
disconnect the connectors
one after the other, continue
with the connectors along
the left side of the circuit
board.
7. The circuit board can be
further removed and more
cables disconnected.
8. Continue until all cables
are disconnected.
9. Assembly takes place in
the reverse order.
10. Check that the all cables
are installed.
NIBE™ F2040Chapter 7 | Component replacement88

Nibe F2040 Specifications

General

Type	Air/water heat pump
Refrigerant	R410A
Operating Temperature Range Heating	-20°C to 35°C
Operating Temperature Range Cooling	10°C to 46°C
Sound Power Level	56-62 dB(A) (depending on model)
