Transport
F370 should be transported and stored vertically in a
dry place. However. the F370 may be carefully laid on
its back when being moved into a building. The centre
of gravity is in the upper part.
R
0
+2
0
-2
1
R
0
HM flow
49 (50) °C
Hot water
51 °C
+2
0
-2
1
R
0
HM flow
49 (50) °C
Hot water
51 °C
R
0
Assembly
■
Position F370 on a firm base that can take the weight,
preferably on a concrete floor or foundation. Use the
product's adjustable feet to obtain a horizontal and
stable set-up.
30 - 50 mm
30 - 50 mm
15 - 40 mm
■
The area where F370 is located must be equipped
with floor drainage.
■
Install with its back to an outside wall, ideally in a
room where noise does not matter, in order to elim-
inate noise problems. If this is not possible, avoid
placing it against a wall behind a bedroom or other
room where noise may be a problem.
■
Wherever the unit is located, walls to sound sensitive
rooms should be fitted with sound insulation.
■
Route pipes so they are not fixed to an internal wall
that backs on to a bedroom or living room.
■
The heat pump's boiler room should always have a
temperature of at least 10 °C and max 30 °C.
Installation area
Leave a free space of 800 mm in front of the product.
Approx. 50 mm free space is required on each side, to
remove the side panels. The panels do not need to be
removed during service, all service on F370 can be
carried out from the front. Leave space between the
heat pump and wall behind (and any routing of supply
cables and pipes), to reduce the risk of any transmission
of vibrations.
* Depending on whether the panels can be removed or not.
NOTE
Ensure that there is sufficient space (300 mm)
above the heat pump for installing ventilation
hoses.
NIBE™ F370Chapter 2 | Delivery and handling8
2 Delivery and handling
