Nibe F370 - Symbol Key; Cold and Hot Water; Heating Medium Side

Symbol key
MeaningSymbol
Venting valve
Shut-off valve
Trim valve
Shunt / shuttle valve
Safety valve
Temperature sensor
Expansion vessel
Pressure gauge
P
Circulation pump
Particle filter
Compressor
Heat exchanger
Cold and hot water
Connecting cold and hot water
A mixer valve must also be installed if the factory set-
ting for hot water is changed. National regulations
must be observed. The setting is made in menu 5.1.1
(page 52).
Heating medium side
Connecting the climate system
NIBE™ F370Chapter 4 | Pipe and ventilation connections16
