Menu system
When the door to the heat pump is opened, the menu
system’s four main menus are shown in the display as
well as certain basic information.
INDOOR CLIMATE
HEAT PUMP INFO
HOT WATER
SERVICE
Indoor temperature - (if room sensors are installed)
Hot water temp.
Temporary lux (if activated)
Outdoor
temperature
Estimated amount of hot water
Information about
operation
Menu 1 - INDOOR CLIMATE
Setting and scheduling the indoor climate. See page
38.
Menu 2 - HOT WATER
Setting and scheduling hot water production. See page
44.
Menu 3 - INFO
Display of temperature and other operating informa-
tion and access to the alarm log. See page 46.
Menu 4 - HEAT PUMP
Setting time, date, language, display, operating mode
etc. See page 47.
Menu 5 - SERVICE
Advanced settings. These settings are not available to
the end user. The menu is made visible by pressing the
Back button for 7 seconds when in the start menu. See
page 52.
Symbols in the display
The following symbols can appear in the display during
operation.
DescriptionSymbol
This symbol appears by the information
sign if there is information in menu 3.1
that you should note.
These two symbols indicate whether the
compressor or addition is blocked in
F370.
These can, for example, be blocked de-
pending on which operating mode is se-
lected in menu 4.2, if blocking is sched-
uled in menu 4.9.5 or if an alarm has oc-
curred that blocks one of them.
Blocking the compressor.
Blocking additional heat.
This symbol appears if periodic increase
or lux mode for the hot water is activated.
This symbol indicates whether "holiday
setting" is active in 4.7.
This symbol indicates whether F370 has
contact with NIBE Uplink™.
This symbol indicates the actual speed of
the fan if the speed has changed from
the normal setting.
This symbol indicates whether solar
heating is active.
Accessory needed.
35Chapter 7 | Control - IntroductionNIBE™ F370
