Nibe FIGHTER 1240 - Connection on Delivery 230 V -5; Tariff Connection 230 V -5; Connection on Delivery 230 V -8, -12

Electrical connection
17
FIGHTER 1240
Connection on delivery
230 V: The heat pump is connected on terminal block
-X9 to 230 V + PE via the junction box with fus-
es.
Connection on delivery 230 V -5
N
L
PE
-X9
Connection on delivery
230 V: The heat pump is connected on terminal block
-X9 to 230 V + PE via the junction box with fus-
es.
Connection on delivery 230 V -8, -12
N
L
PE
-X9
