Control
FIGHTER 1240
32
Main menus
Menu 1.0 Hotwatertemperature
The current water temperature (142) in the upper part
of the hot water cylinder is shown here.
Menu 2.0 Flow temperature
The current supply temperature (89) for the heating
system is shown here with the calculated flow temper-
ature in brackets.
Shown alternately with hot water charging, HW charg-
ing.
Menu 4.0 Outdoor temperature
The current outdoor temperature is shown here.
Menu 5.0 Brine in-/out- temp.
Readings regarding the temperatures and compressor
are made from the sub-menus to this menu.
Menu 8.0 Other settings
Settings regarding the menu type, language, operat-
ing mode settings and load monitor reading are made
in the sub-menus to this menu.
Menu 9.0 Service menus
This menu and its submenus are only shown on the
display screen when access has been selected in
menu 8.1.1.
Values can be read and various settings can be made
from these submenus. NOTE! These settings should
only be made by persons with the necessary exper-
tise.
57.1°C
Hotwatertemperature
1.0
31.7 (28.0)°C
Flow temperature
2.0
10.3°C
Outdoor temperature
4.0
Menu 7.0 Clock
Settings regarding the date and time are made in the
sub-menus of this menu. Also different temperature
reductions and increases at selected times are set
from this menu.
Clock
7.0
Other settings
8.0
Service menus
9.0
N
N
N
N
N
N
N
N
N
U
S
S
Normal, covers the normal user's needs.
Extended, shows all menus except the
service menus.
Service, shows all menus, returns to the
previous menu level 30 minutes after the
last button was pressed.
1.0 -2.0°C
Brine in-/out-temp.
5.0
Menu 3.0 Flow temp. system 2*
The current flow temperature (FG2) for the heating
system is shown here with the calculated flow temper-
ature in brackets.
Activated in menu 9.2.5. Note! The flow line tempera-
ture in heating system 2 cannot be greater than in
heating system 1 when heat is shunted in from heat-
ing system 1.
27.7 (24.0)°C
Flow temp. system2
3.0
* Accessories
Menu 6.0 Room temp./Settings*
The room temperature is shown here and the set
room temperature in brackets. Settings concerning the
factor for the room sensor or room unit and which sys-
tem the sensor should control are made on the sub-
menus to this menu. The accessory RG 10 is activat-
ed in menu 6.0.
21.3 (21.0)°C
Room temp./Settings
6.0
