Nibe FIGHTER 1240 - Technical Specifications 3 X 230 V

Technical specifications
59
FIGHTER 1240
* Compressor output only.
** Refers to the brine flow temperature/heat medium flow temperature in accordance with EN 255.
*** With feet and connections dismantled the height is 1890 mm.
Type 6 8 10 12
Operational voltage (V) 3 x 230 V + N + PE 50 Hz
Max operating current, compressor (A) 7,5 10,0 12,3 18,0
Max operating curr. incl. immersion heater 6 kW (A)
28,2 30,7 33,0 38,7
Output, HC pump (W) 75 75 75 170
Connection heating medium, o.d. ø (mm) 22
Max pressure in storage heater (MPa) 0.9 (9 bar)
Refrigerant quantity (R407C) (kg) 1,7 2,2 2,4 2,4
Pressure drop, evaporator (kPa) 11 12 11 15
Max pressure collector system (bar) 3
Heating medium flow (l/s) 0,13 0,18 0,22 0,26
Max temp. (flow/return circuit) (°C) 60/50
IP 21
Volume, water heater (litres) 160
Starting current, compressor (A) 60 115 138 145
Max operating curr. incl. immersion heater 4 kW (A) 21,9 24,3 26,6 32,3
Output, brine pump (W) 130 170 170 250
Connection brine o.d. Ø (mm) 28
Volume, double-shelled (litres) 45
Max pressure in double jacket volume (MPa) 0.25 (2.5 bar)
Brine flow (l/s) 0,35 0,48 0,58 0,65
Available pressure, collector system (kPa) 55 51 48 65
Operating temperature collector system (°C) -5 +20
Cut-out value pressostat HP (bar) 27
Difference pressostat HP (bar) -7
Cut-out value pressostat LP (bar) 1,5
Enclosure class IP 21
Difference pressostat LP (bar) +1,5
Net weight (kg) 285 300 305 310
Delivered/supplied power* at 0/35 °C **
6,0/1,3 8,8/1,9 10,3/2,2 11,7/2,5
Delivered/Supplied power * at 0/50 °C **
4.8/1.5 7,1/2,2 8,5/2,5 9,9/2,9
Required ceiling height (mm) 1950 ***
Pressure drop, condenser (kPa) 2,6 3,4 3,2 4,4
Technical specifications 3 x 230 V
Part no. Enamel — — — –
Part no. Stainless steel 665 100 665 101 665 102 665 103
Part no. Copper — — — —
