Service menus
FIGHTER 1240
44
Operating settings
Menu 9.2.5 System 2 Present
This menu is used to select On or Off depending on
whether you have shunt group 2 (accessory ESV 21
needed).
Off
System 2 Present
9.2.5
Menu 9.2.6 Room disp Present
Select here whether the Room control unit is to be
activated or not. The value is adjustable “On” or “Off”.
Changes to “Off” with a restart.
Off
Room disp Present
9.2.6
S
S
Menu 9.2.4 Add heat only
Only additional heat is activated when On is shown on
the display, otherwise Off is shown. When only addi-
tional heat is activated, the immersion heater respec-
tive circulation pump cannot be blocked with the oper-
ating mode button. NOTE! Select Off to deactivate
only additional heat and select the required oper-
ating mode using the operating mode button.
Off
Add heat only
9.2.4
S
Menu 9.2.7 Circ. pump 1
Here you set whether heat medium pump should run
constantly in Summer mode. The value can be set On
or Off. Changes to Off with a restart.
Off
Circ. pump 1
9.2.7
S
Menu 9.2.8 Circ. pump 2
Here you set whether heat medium pump 2 should run
constantly in Summer mode. The value can be set On
or Off. Changes to Off with a restart.
Off
Circ. pump 2
9.2.8
S
Menu 9.2.9.0 Floor drying set
Settings for the floor drying program are made in the
sub-menus to this menu.
Floor drying set
9.2.9.0
S
Menu 9.2.0 Operating mode set
Settings regarding supplementary heat, floor drying
and a return to the factory settings can be made on
the sub-menus in this menu.
Operating mode set
9.2.0
Menu 9.2.1 Max HW temp
Here the maximum boiler temperature is shown. The
value is selected on the load monitor card using knob
(102).
65°C
Max HW temp
9.2.1
S
S
Menu 9.2.2 Flow diff HP
When the current flow temperature deviates from the
set value compared to that calculated, the heat pump
is forced to stop/start irrespective of the degree minute
figure.
When the current flow temperature exceeds the cal-
culated flow by the set value the degree-minute figure
is set to 1. The compressor stops when there is only a
heating requirement.
When current flow temperature falls below the calcu-
lated flow by the set value the degree-minute figure is
set to -60. This means the compressor will start. When
the value also falls below menu 9.2.3, the degree-
minute figure can be set to -400. The value is
adjustable between 3 and 25 °C.
13°C
Flow diff HP
9.2.2
S
Menu 9.2.3 Diff HP Add
When the current flow temperature drops below that cal-
culated by the set value plus the value from menu 9.2.2
the degree-minute value is set to -400. This means that
the additional heat can be engaged directly. The value is
adjustable between 1 and 8 °C.
3°C
Diff HP Add
9.2.3
S
