Control
FIGHTER 1240
38
Brine in/out temperature
Menu 5.5 Status compressor
Shows the compressor status for the heat pump.
Start in XX minutes, means the compressor will start
as soon as the time condition permits.
Compr. OFF means that the compressor is not opera-
tional.
Compr. ON means that the compressor is operational.
Brine pump On means the brine pump is running.
Start in 5 min
Status
5.5
N
Menu 5.4 Compr. starts at
How low the degree-minutes may drop before the
compressor start can take place is set here. The value
is adjustable between -5 and -250.
-60
Compr. starts at
5.4
N
Menu 5.6 Number of starts
The accumulated number of starts with the compres-
sor is shown here.
82
Number of starts
5.6
U
Menu 5.9 Comp. acc. run time
The accumulated time that the compressor has been
in operation is shown here.
112h
Comp. acc. run time
5.9
U
Menu 5.11 Hot gas temp.
The hot gas temperature is shown in this menu.
104°C
Hot gas temp.
5.11
U
Menu 5.12 Liquide line Temp.
The fluid line temperature is shown in this menu.
48.2°C
Liquide line temp.
5.12
U
Brine in/out temperature
Menu 5.13 Bulb temperature
The suction gas temperature is shown in this menu.
5.0°C
Bulb temperature
5.13
U
Menu 5.22 Max temp cond. flow
This menu shows the max permitted temperature for
condenser flow line.
65°C
Max temp cond. flow
5.22
U
Menu 5.23 Return temp max
This menu displays the max permitted return line tem-
perature.
53°C
Return temp max
5.23
U
Menu 5.14 Condensor out temp.
The heat medium temperature after the condensor is
shown here.
Condensor out temp.
5.14
U
Menu 5.24 Return
Pressing the enter button returns you to menu 5.0.
Return
5.24
