Setting the automatic heating control system
20
For the Installer
FIGHTER 600P
FIGHTER 600P is equipped with outdoor temperature
controlled automatic controls. This means the flow
temperature is regulated in relation to the current out-
door temperature.
The relationship between outside temperature and
flow temperature is set with the Heating curve selec-
tion and Offset, heating curve knobs.
The diagram is based on the dimensioned outdoor
temperature in the area and the dimensioned flow
temperature of the heating system. When these two
values meet, the heating control’s curve slope can be
read.
Set the Offset, heating curve accordingly. A suitable
value for floor heating is -1 and for radiator systems -
2.
To read the calculated flow temperature, go to chan-
nel selection 10.
Also see section Room temperature.
30
40
50
60
70
°C
FRAMLEDNINGSTEMPERATUR
- 40 °C
UTETEMPERATUR
- 10
0
10
- 20 - 30
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
KURVLUTNING
- 5
+ 5
PARALLELLFÖRFLYTTNING
15 14 13 12 11 10
9
8
7
6
5
4
3
2
1
- 40 °C
UTETEMPERATUR
- 10
0
10
- 5
+ 5
30
40
50
60
70
°C
FRAMLEDNINGSTEMPERATUR
- 20 - 30
PARALLELLFÖRFLYTTNING
KURVLUTNING
1514 13 12 11 10
8
7
6
5
4
3
2
1
- 40 °C
UTETEMPERATUR
- 10
0
10
- 5
+ 5
30
40
50
60
70
°C
FRAMLEDNINGSTEMPERATUR
- 20 - 30
PARALLELLFÖRFLYTTNING
9
KURVLUTNING
Heating curve offset 0
Heating curve offset -2 Setting using diagrams
Heating curve offset +2
HEATING CURVE
HEATING CURVE
HEATING CURVE
HEATING CURVE
OFFSET
HEATING CURVE
OFFSET
FLOW TEMPERATURE
FLOW TEMPERATURE
FLOW TEMPERATURE
OUTSIDE TEMPERATURE
OUTSIDE TEMPERATURE
OUTSIDE TEMPERATURE
HEATING CURVE
OFFSET
