Docking
31
For the Installer
FIGHTER 600P
During low tariff, FIGHTER 600P now provides, func-
tionally separate from the accumulator tank without
external help, ventilation, radiator heating and hot tap
water. If additional energy is required this is provided
by the immersion heater in FIGHTER 600P.
The accumulator tanks are charged independent of
the FIGHTER 600P until the preferred tank tempera-
ture has been reached.
NOTE!
SK11 is not approved for more than 16
A, which means the total output of the
accumulator tanks’ electrical
supplement combined must not exceed
11 kW
Low tariff
In order to utilise special tariffs the FIGHTER 600P
can be supplemented with an accumulator tank (with
immersion heater), which supplies a heat supplement
during off peak times. Energy is supplied when a cir-
culation pump starts and pumps the externally heated
water to the FIGHTER’s heating circuit. This takes
place until there is no longer a need of the energy sup-
plement.
An appropriate size of accumulator tank must be cho-
sen according to individual needs.
Docking to the accumulator tank
The fan, circulation pump and compressor in
FIGHTER 600P work as before. If supplementary
energy is required this is taken from the accumulator
tanks. If the stored energy is not sufficient in cold
weather conditions or with abnormally high hot water
consumption, the immersion heater in FIGHTER can
be connected to cover the energy requirement.
High tariff
In addition to FIGHTER 600P the system consists of
one (or more) accumulator tank (s) PS 500 and a
docking kit PSP 11 (for one accumulator tank) or PSP
21 (for two accumulator tanks). The connection kit
consists of a connection box SK11, a Laddomat LGT
10, a trim valve, one or two immersion heaters, a ther-
mostat, which is placed high up in the accumulator
tank as well as connection instructions.
Equipment
Connection box SK 11
Connecting with
FIGHTER 600P
