Nibe FIGHTER 600P - Technical Specifications

Technical specifications
29
For the Installer
FIGHTER 600P
Rated output, compressor 1.0 kW
Required ceiling height 2 197 mm
Depth 640 mm
Volume total 244 litres
Volume water heater 189 litres
Supply voltage 400 V~ 3-phase + N
Rated output circulation pump 100 W (adjustable)
Max pressure in storage heater 0.9 MPa (9 (bar)
Fuse pressure in boiler section 0.25 MPa (2.5 (bar)
Refrigerant type R290 (propane)
Max pressure in boiler section 0.25 MPa (2.5 (bar)
Breaking value, high pressure pressostat 2,45 MPa (24.5 (bar)
Height 2 110 mm
Width 600 mm
Net weight 210 kg
Volume boiler section 55 litres
Volume, expansion vessel 10 litres
Output immersion heater 9.0 kW (reconnectable)
Rated output fan 170 W (adjustable)
Enclosure class IP 21
Breaking value, low pressure pressostat 0,15 MPa (1.5 (bar)
Refrigerant volume 380 g
Sound level in the boiler house 40 – 45 dBA
IP 21
