Symbol key
MeaningSymbol
Shut-off valve
Tapping valve
Non-return valve
Shunt / shuttle valve
Safety valve
Thermometer
T
Trim valve
Temperature sensor
Expansion vessel
Pressure gauge
P
Circulation pump
Particle filter
Flow meter EMK 310
Heat exchanger
11Chapter 4 | Pipe connectionsNIBE™ VVM 310
