NOTE
Mark up any junction boxes with warnings for
external voltage.
L
L
N
N
PE
PE
F1X45
Externt
$$;
&121&
([WHUQDO
990
&LUFXODWLRQ SXPS
APH
VVM 500
AA3-X7
Caution
The relay outputs can have a max load of 2 A
(230 V AC) in total.
Connecting accessories
Instructions for connecting accessories are provided in
the manual accompanying the accessory. See page 60
for the list of the accessories that can be used with VVM
310.
NIBE™ VVM 310Chapter 5 | Electrical connections28
