Installation alternative
Compatible NIBE air/water heat pumps
Compatible NIBE air/water heat pumps must be
equipped with a control card with display that has the
software version given in the following list as a minim-
um. The control card version is displayed in the heat
pump's display upon start-up.
Software versionProduct
55F2015
55F2016
55F2025
55F2026
all versionsF2030
all versionsF2040
55F2300
VVM 310 can be connected to extra water heater, see
below.
Further option information is available at www.nibe.eu
and in the respective assembly instructions for the ac-
cessories used. See page 60 for a list of the accessories
that can be used with VVM 310.
Extra hot water heaters
Water heater with immersion heater
If it is possible to use a water heater with an immersion
heater, NIBE COMPACT or EMINENT type water heaters
can be used.
If the heater is equipped with a valve connector Ø 15
mm this should be replaced with a corresponding Ø
22 mm.
Kv
Vv från värmepump
Backventil
Blandningsventil
+: IURP 990 
&:
1RQUHWXUQ YDOYH
+:
0L[LQJ YDOYH
