Nice 3501

36
PARTS LIST
DESCRIPTION
PART NUMBER
QTY
ITEM
Post Mount Plate
100383151 1
Toggle Switch Assembly
10024290 1 2
3500 Cover Box100314901 3 Flange Bearing 72510000 2 4 Top Chassis
Bottom Chassis
10041715 10041815
1 5
Surge Board Bracket
10028290 1 6
Limit Block Assembly
100241902 7
Surge Board
755900131 8
Collar & Magnet Assembly100214902 9 Gearmotor Spacer10041615
1
10
Torque Limiter
10040690
11 1
Sprocket
21 1 41B05
Gear Motor7309000531 1
1 1
2 2
A A
B B
TITLE
1
2
4
5
6
7
8
9
11
10
12
13
CHBOX350 - 3500 Motor Chassis Assembly
Nice Gates
3
NOTE: THESE ITEMS ARE ALSO
SOLD AS ONE UNIT
Name: Limit Sub Assembly
Part# 10052490
