16 – English
7.4 - Level 2 Functions (adjustable parameters)
Level 2: the parameters can be adjusted on a scale of values (from 1 to 8); in this case, each of the LEDs L1….L8 indicates the
set value among 8 possible settings; refer to Table 7.
Table 7 - Programmable functions: Level 2
LED
Parameter
Level Value Description
Note: the parameters with a grey background are factory settings
L1
5 s
Adjusts the pause time, that is, the time that
elapses before automatic re-closure. Is effective
only if automatic closure is enabled
L2
15 s
L3
30 s
L1 Pause Time L4
45 s
L5
60 s
L6
80 s
L7
120 s
L8
180 s
L1 Open - Stop - Close - Stop
Adjusts the sequence of commands associated
with the Step-by-Step input or the 1st radio com-
mand
L2 Open - Stop - Close - Open
L3 Open - Close - Open - Close
L2
Step-by-Step
function
L4 Apartment block
L5 Apartment block 2 (more than 2” gen-
erates stop)
L6 Step-by-Step 2 (less than 2” causes
partial opening)
L7 Hold-to-run
L8 “Semi-automatic” opening, “hold-to-
run” closing
L1 Very slow
Adjusts the motor speed during normal travel.
MODEL 500HS: factory setting = L5
L2 Slow
L3 Medium
L3 Motor speed
L4 Fast
L5 Very fast
L6 Extremely fast
L7 Opens “Fast”, Closes “Slow”
L8 Opens “Extremely fast”, Closes “Fast”
L1 “Gate Open Indicator” (G.O.I.) function
Adjusts the function associated with G.O.I. out-
put (whatever the associated function, the output
supplies a voltage of 24 V –30 +50% with a maxi-
mum power of 4 W when active)
L2 On if gate closed
L3 On if gate open
L4 G.O.I. output
L4 Active with radio output no. 2
L5 Active with radio output no. 3
L6 Active with radio output no. 4
L7 Maintenance indicator
L8 Electric lock
L1 Ultra-light gate
Adjusts the system that controls the motor force
in order to adapt it to the weight of the gate. The
force control system also measures the ambient
temperature, automatically increasing the force in
the event of particularly low temperatures
L2 Very light gate
L3 Light gate
L5 Motor force
L4 Average gate
L5 Medium-heavy gate
L6 Heavy gate
L7 Very heavy gate
L8 Ultra-heavy gate
L1 0.5 m
Adjusts the measurement of the partial opening.
Partial opening can be controlled with the radio
command no. 2 or with “CLOSE”, if the “Close”
function is present, this becomes “Partial open”
L2 1 m
L3 1.5 m
L6 Partial open
L4 2 m
L5 2.5 m
