2.5 PROFINET IO communication module
The PROFINET IO communication module (GB40A-PROFINET expansion board, code 1000256531) provides the PROFINET communication bus;
it is connected to the BASIS control board via J7 and J8.
The physical interfaces are 2 RJ45 connectors to connect Ethernet cables.
Technical data
Operating temperature, -20°C - +50°C
Storage and transport temperature, -20°C - +70°C
LED
Abbreviation
Colour
Function
DL 1
Green
Vcc Power
DL 2
Green
Network status
DL 3
Red
Error
DL 4
Green
Module configured
DL 5
Red
Fault
DL 6
Green
Port A Eth Link Activity
100Mb
DL 7
Red
Port A Eth Link Activity
10Mb
DL 8
Green
Port B Eth Link Activity
100Mb
DL 9
Red
Port B Eth Link Activity
10Mb
The GB40A-PROFINET expansion board is an option indicated by the letter I in the 13
th
character of the identification code (see chapter 2 of the User
and Maintenance Manual):
AD3
A
XXX
F
B
N
F
H
I
C
N
00
NN
